Truly See-Through Installations

undefined

The first-of-its-kind Planar LookThru transparent OLED display is a self-emitting display that utilizes cutting-edge Organic Light Emitting Diode (OLED) technology to eliminate the need for a backlight or enclosure, making it possible to create truly see-through installations. It offers virtually frameless glass with 45 percent light transmissivity, creating clear, unobstructed views of objects, scenes, or other digital screens behind the transparent display.

Flexible Design Options

The Planar LookThru transparent OLED display measures 55-inch in diagonal. It can be used in both portrait and landscape modes, can be table mounted, ceiling mounted, or built into custom fixtures using the straight flush-mount design. It can also be tiled to create large, eye-catching video wall arrays. The Planar LookThru display is available with optional touch screen interactivity, offering 32 simultaneous touch points.

High Durability

The Planar LookThru transparent OLED display features the proprietary Planar® Extended Ruggedness and Optics™ (ERO™) technology, which uses a protective optically-clear Corning® Gorilla® Glass bonded to the front surface of the display. This high-durability surface can withstand the rigors of high-traffic environments and interactive touch. This technology also improves perceived contrast by more than 300 percent when compared to traditional large format cover glass, making the display more readable and impactful even in bright public venues.

Brilliant Picture Quality in a Large Viewing Size

The Planar LookThru transparent OLED display offers vibrant colors greater than 100 percent National Television System Committee (NTSC) performance as well as wide viewing angles with no off-axis contrast or brightness limitations. The display provides Full HD resolution that delivers beautiful graphics and full-motion video.


Source Compatibility

The Planar LookThru transparent OLED display comes with standard digital inputs including HDMI and DisplayPort, is fully controllable using RS-232, LAN, Crestron and other control systems, and is compatible with sources ranging from PCs and players to consumer video devices that rely on High-bandwidth Digital Content Protection (HDCP) compliance. The display is compatible with processing solutions from Planar including the Clarity® Visual Control Station™ (VCS™) for tiling applications or advanced source management.

Accessories for Tiling, Mounting and Staging

To further expand application capabilities with Planar LookThru transparent OLED displays, a range of accessories is available. Accessories include four tiling components that cater to multi-display tiling and designs featuring flat or corner configurations. Additional accessories available include Base Plates for securing Planar LookThru displays to ceilings, tables and walls, as well as a Platform Cover that creates a staging surface for items placed behind the display while protecting the Planar LookThru display’s electrical components.


Model NumberPart Number
LO55 997-8219-00
LO55-T 997-8244-00
LO55-S 997-8220-00
LO55-s-T 997-8245-00
